Download the PDF Catalogue for Infiniti/Challenger Printer FY-3286J
FY-3286J 6-color eco-solvent printer is equipped with 508GS industrial grayscale print heads. Each print head is 71.8mm in width and has 508 jet holes. Due to the high-performance print heads, maximum printing speed of the 6-color printing machine can be as high as 96m2/h and its maximum printing precision can be 1440dpi.
Application
FY-3286J eco-solvent inkjet priner is suitable for printing on lamp cloth, self adhesive vinyl, gridding cloth, banner
Features
1. FY-3286J 6-color eco-solvent printer supports 4-level grayscale printing with the minimum ink droplet of 12pL.
2. Eco-solvent ink which is non-toxic and odorless is used in this product.
3. Intelligent tension and medium control system allows the printing medium to feed in easily without deviation. This system can also achieve automatic medium take-up.
4. This eco-solvent inkjet printing equipment is configured with a heating system for the front, middle and rear platen as well as a far infrared hot air & cool air drying system. The heating and drying systems make for rapid image drying.
5. The platen and the beam are made of superior aluminum alloy, thus are solid and flat.
6. LED illuminating lamp makes printing image easy to be seen.
7. Atomizing ink jetting system prevents the occurrence of PASS line and assures the quality of the printed image
8. Equipped with a heating system for the print head, FY-3286J 6-color eco-solvent printer is able to work in low temperature environment.
9. 10 high power cooling fans and 10 PET hot air fans accelerate image drying.
Equipped with industrial piezo printhead which comes with 508 nozzles,printing width of 72mm.,and 720DPI printing resolution.
◆ 4level grey scale printhead with min.14pl ink drop size at double 4 colors, to reach a perfect combination of resolution and speed;
◆ Non-toxic,odorless and environment friendly ink;
◆ Smart tension control system brings excellent media moving;
◆ Complete heating & drying system,front,print and rear built-in heaters,IR and cooling fan dry system;
◆ Printhead heating system for low temperature printing environment.
Detail Sepcificatons:
MODEL | FY-3286J | ||
Printhead SII Printek Inc. |
SPT508GS | ||
Number of printhead | 4/6 Heads | ||
Output Quantity (m2/h) | Print Mode | Outputs(m2/h) | |
Draft | 2Pass | 91 | |
Standard | 3Pass | 61 | |
Quality | 4Pass | 46 | |
High Quality | 6Pass | 31 | |
Back-lit | 8Pass | 23 | |
Max. printing width | 3200mm | ||
Max. media width | 3300mm | ||
Ink | Type | Solvent or Eco-solvent | |
Color | (C,M,Y,K) or (C,M,Y,K,Lc,Lm) | ||
Volume | 2 liters main tank | ||
Ink supply system | Ink level sensor. Auto-pumping | ||
Media | Width | 3300mm | |
Type | Banner, vinyl, polyester, etc | ||
Feeding System | Single or double feeding bar. (Max weight 80kg) | ||
Ph. Cleaning System | Individual color purging | ||
Heating System | Back, middle, front, and extra heater. | ||
Clamp | Equipped | ||
Printhead Height | Adjustable distance from 2mm~6mm. | ||
Input Voltage | AC220V,50Hz/60Hz | ||
Printer Dimension/Weight | L4766xW930xH1350mm /640Kg | ||
Package Dimension/Weight | L4980xW1140xH1620mm / 923Kg |
AllSign Printer - Infiniti FY-3286J with Seiko SPT508GS heads.
AllSign Printer - Infiniti FY-3286J with Seiko SPT508GS heads.
The picture is only for reference,please make the object as the standard.
The Speed data varies in different computer.
Inkjet printer prints with fine ink dots, so the printing colors may be different along with the chnage of printheads. When printing with serveal printers at the same time, a difference in printing colors may exists due to a difference exist in every single printer.
But as far as we know, most for the operation is similar for different printer.
