Solvent Outdoor Banner Printer Challenger FY-3206T (6pcs Seiko SPT510/35PL Heads)

Solvent Outdoor Banner Printer Challenger FY-3206T (6pcs Seiko SPT510/35PL Heads)

Download the PDF Catalogue for Infiniti/Challenger Printer FY-3206T



Equipped with industrial piezo printhead which comes with 510 nozzles,printing width of 71.8mm,and 720dpi printing resolution.

◆ 6 color printing,the standard output achieves 44㎡/hr.

◆ AC servo motor is used to run the carriage quicker and more stable.

◆ Individual color purging minmizes the waste of the ink.

◆ 3 way intelligent heater helps bring more vivid output.

◆ The entire printing platform and the girder are made of the alloy-aluminum which is more strong and flat.

Solvent Outdoor Banner Printer Challenger FY-3206T Specifications:

Model FY-3206T
PrintHead Drop on demand PiezoHead
Number of Printhead 6 Heads
Maximun Print Width 3200mm(125.98")
PrintSpeed 360×360dpi 1Pass 54㎡/hr
240×720dpi 2Pass 44㎡/hr
240×1080dpi 3Pass 27㎡/hr
360×1080dpi 3Pass 16㎡/hr
Media max.width 3300mm(129.92")
Max.Weight 80kg
Type Frontlit,Backlit,Vinyl,Polyester,WindowFilm,Leater…
thickness 4mm(Max)
HeatingSystem 3 way intelligent heater
AutoMediaFeeding&Take-upSystem Equipped
Ink Type Solvent ink(C、M、Y、K)
Capacity 1L o r5L per Colo rMainTank
AutoCleaningSystem Positive Pressure Cleaning, Anti-Clogging Flash Function&Capping System
Printinterface Optical Fiber/USB2.0
PowerSpecification 220V/230V50Hz/60Hz Printer:660W Heater:1900W
OperationalEnvironment Temperature:20℃-28℃ Humidity:40%-60%
CompatibleRIPSoftware Photoprint,UltraPrint,Topaz,Wasatch,Caldera,Maitop
Dimension&Weight Machine L4500mm×W905mm×H1260mm363kg
Package L4630mm×W1050mm×H1520mm625kg

Solvent Outdoor Banner Printer Challenger FY-3206T Photos

Solvent Outdoor Banner Printer Challenger FY-3206T AllSign Printer -Solvent Outdoor Banner Printer Challenger FY-3206T. Solvent Outdoor Banner Printer Challenger FY-3206T AllSign Printer -Solvent Outdoor Banner Printer Challenger FY-3206T. Solvent Outdoor Banner Printer Challenger FY-3206T AllSign Printer -Solvent Outdoor Banner Printer Challenger FY-3206T. Solvent Outdoor Banner Printer Challenger FY-3206T AllSign Printer -Solvent Outdoor Banner Printer Challenger FY-3206T.

Solvent Outdoor Banner Printer Challenger FY-3206T AllSign Printer -Solvent Outdoor Banner Printer Challenger FY-3206T. Solvent Outdoor Banner Printer Challenger FY-3206T AllSign Printer -Solvent Outdoor Banner Printer Challenger FY-3206T. Solvent Outdoor Banner Printer Challenger FY-3206T AllSign Printer -Solvent Outdoor Banner Printer Challenger FY-3206T. Solvent Outdoor Banner Printer Challenger FY-3206T AllSign Printer -Solvent Outdoor Banner Printer Challenger FY-3206T.

The picture is only for reference,please make the object as the standard.
The Speed data varies in different computer.
Inkjet printer prints with fine ink dots, so the printing colors may be different along with the chnage of printheads. When printing with serveal printers at the same time, a difference in printing colors may exists due to a difference exist in every single printer.
