Konica 512i Printer CK512i with KM512iLNB/30PL Printhead

Konica 512i Printer CK512i with KM512iLNB/30PL Printhead

Download the PDF Catalogue for Konica Solvent Printer CK512i



Brand Sparepart Standard Setup
BYHX-A-KM512i-8H Boards
Honsoft UltraPrint RIP software
Japanese PANASONIC 400W AC servo motor
Japanese NSK bearing
JapaneseTHK linear guide with two pcs mute slider
Italy Megadyne 25 MM belt
American Value Plastics tube connector
Germany IGUS drag train
Germany IGUS Power cable
JYY Air pump
JYY DC ink Pump
JYY Solenoid Valve
Classic Printer body
16*6 CM main beam for the body
12MM Y motion axis
4.2 M  Aluminum beam for carriage
High quality 200mm wide printing bed
Aluminum XY holders
Positive pressure ink supply system
Intelligent infrared heating system
Rear-Printing bed-front-Printhead heater
Adjustable vacuum for Printing bed
Lift type carriage
Unique printhead protection stack
4 in 1 heating control system
LED lights at cleaning postion and printing bed
Take up system (Optional)
Tarpaulin holding system (Optional)
Multifunction Feeding system


Printing speed and Resolution
4H-2pass-120㎡/h-480*360dpi
4H-3pass-80㎡/h-480*540dpi
4H-4pass-60㎡/h-480*720dpi

8H-2pass-240㎡/h-480*360dpi
8H-3pass-160㎡/h-480*540dpi
8H-4pass-120㎡/h-480*720dpi

1. It has 512 nozzles which firing frequency has increased 4 times, each nozzle can jet 30000 droplets in one second;

2. It adopts 30PL droplet size, which can enhance picture quality in short distance observation.

3. Nozzle density has developed from 360dpi to 180dpi, so the width of single pass has increased by one time.(512 i/30pl printhead size is equal to 2 pieces of 512/42pl printheads)

Konica Solvent Printer CK512i with KM512iLNB/30PL Printhead

Model No. CK512i
Printhead Type KM-512iLNB-30PL
Printhead Type 8 Printhead (two line arrangement)
Ink Type Solvent Ink
Maximum Print Width 320cm
Ink Capacity 5000cc/color
Heating System Pre, Mid, Post Heater 30C-65C
Cooling System Cooling System, 3-section IR heating system
Auto Feed in / Take Up Feed in System Standard, Take up System Optional
Environment / Power Temperature 15-35℃, Humdity 40%-65%, 50Hz, 220V(±10%), >20A
Machine Size 4.84m x 1.12m x 1.49m



Konica Solvent Printer CK512i with KM512iLNB/30PL Printhead

Konica Solvent Printer CK512i with KM512iLNB/30PL Printhead

Konica 512i Printer CK512i Photos

AllSign Printer -Konica Solvent Printer CK512i with KM512iLNB/30PL Printhead. AllSign Printer -Konica Solvent Printer CK512i with KM512iLNB/30PL Printhead. AllSign Printer -Konica Solvent Printer CK512i with KM512iLNB/30PL Printhead.

Konica 512i Printer CK512i with KM512iLNB/30PL Printhead AllSign Printer -Konica Solvent Printer CK512i with KM512iLNB/30PL Printhead. Konica 512i Printer CK512i with KM512iLNB/30PL Printhead AllSign Printer -Konica Solvent Printer CK512i with KM512iLNB/30PL Printhead. Konica 512i Printer CK512i with KM512iLNB/30PL Printhead AllSign Printer -Konica Solvent Printer CK512i with KM512iLNB/30PL Printhead.

The picture is only for reference,please make the object as the standard.
The Speed data varies in different computer.
Inkjet printer prints with fine ink dots, so the printing colors may be different along with the chnage of printheads. When printing with serveal printers at the same time, a difference in printing colors may exists due to a difference exist in every single printer.
